RS80-1B-14T SIMPLEX SPROCKET FOR H-Beam PTW Welding Machine Sprocket
Part Code: RS80-1B-14T
Part Name: SIMPLEX SPROCKET FOR H-Beam PTW Welding Machine Sprocket
Part Name: SIMPLEX SPROCKET FOR H-Beam PTW Welding Machine Sprocket
Part Code: RS80-1B-14T
Usage: This sprocket used in the manufacturing of H-beam PTW welding machines for reliable roller chain drive operation and heavy-duty load transfer.
Application of H-Beam PTW Welding Machine Sprocket
Built for Heavy-Duty Welding Line Power Transmission:
Designed for H-beam PTW welding machines, this sprocket delivers reliable and consistent roller chain drive performance—essential for handling heavy loads in automated structural fabrication systems.
Optimized for Industrial Fabrication & Multi-Axis Welding:
Ideal for manufacturers of steel structures and heavy fabrication machinery, ensuring stable motion control during critical welding, positioning, and material-transfer operations in PTW lines.
Trusted in High-Load Welding Environments:
Frequently used in PTW welding systems developed by industrial automation and fabrication equipment makers, supporting long operating cycles and demanding load conditions.
Summary
A high-strength sprocket engineered for H-beam PTW welding machine production lines, offering rigid construction, reliable torque transfer, and long-lasting performance for demanding structural fabrication processes.
| Parameter | Value / Description |
|---|---|
| Application | Used in the manufacturing of H-beam PTW welding machines for main roller chain drive and load transfer |
| Chain Standard | ANSI 80-1 (RS80-1B) Simplex Roller Chain |
| Number of Teeth | 14 |
| Pitch | 25.40 mm (1") |
| Pitch Circle Diameter (PCD) | 126.50 mm |
| Bore Diameter | 55.00 +0.04 mm (with keyway) |
| Keyway | Full length keyway, details per shaft fit |
| Hub Type | Double hub (center boss both sides) |
| Hub/Boss Diameters | 80 mm (main hub), overall width 84.6 mm |
| Hub Widths | 45 mm (one side), 25 mm (other) |
| Face Width (Total) | 16 mm sprocket plate thickness |
| Tooth Width/Flat Top | 12.88 mm top land (see profile detail) |
| Chamfer | 2.5 x 45° at ends |
| Relief/Features | Chain clearance profiles as per drawing |
| Material Property | EN-8 (medium carbon steel) |
| Surface Treatment | Blackening |
| Total Weight | 2 KG |
| Teeth Details | As per DIN/ISO standard |
| Sample Chain Pull (F) | 3500 N |
| Sample Sprocket Speed (N) | 25 RPM |
| Sample Torque (T) | ~221 Nm |
| Sample Power (P) | ~0.58 kW |
